NEMA 17 Bipolar 1.8deg 0.16Nm 0.7A 3.1V 42x42x25mm Stepper Tsav

NEMA 17 Bipolar 1.8deg 0.16Nm 0.7A 3.1V 42x42x25mm Stepper Tsav

Tus lej naj npawb:42H025H-0704-002
Ncej Loj: 42x42mm
Lub cev muaj zog: Bipolar Stepper
Tuav Torque: 1.6 kgf.cm
Rated Tam sim no/theem: 0.7 A
Kev ntsuas hluav taws xob: 3.1V
Connector: S6B-PH-KS
Daim ntawv thov: 3D tshuab luam ntawv, CNC tshuab, Textile Machinery, thiab lwm yam

Xa kev nug
42H025H-0704-002DADASHEET
  • Kev xa khoom sai
  • Quality Assurance
  • Customization AvailableCustomization Muaj
Khoom Taw qhia

General Specification

Kauj ruam Angle Accuracy

±5%

Resistance raug

±10%

Inductance Qhov tseeb

±20%

Kub nce

80k Max.

Ambient Kub

-20 degree ~ +50 degree

Rwb thaiv tsev Resistance

100MΩMin.@500VDC

Dielectric zog

Ib feeb @ 500VAC∙5mA Max.

Ncej Radial Ua Si

0.06Max.@450g

Ncej Axial Ua Si

0.08Max.@450g



Hluav taws xob Specification

Qauv nab npawb 42H025H-0704-002
Hom Tsav Bipolar
Kauj ruam 1.8 degree ± 5%
Tus naj npawb ntawm Theem 2
Tuav Torque 1.6 kqf ua
Rated Tam sim no / theem 0.7 A (tus nqi siab tshaj)
Rated Voltage 3.1 V
Phase Resistance 4.4 Ω ± 10% (20 degree)
Theem Inductance 5.5 mH ± 20% (1kHz 1V RMS)
Rotor Inertia 26 g.m xoj



Lub cev Specification

Ncej Loj 42 x 42 mm
Lub cev Ntev 25 mm
Ncej kab Φ5 hli
Pem hauv ntej Ncej Length 20 mm
Qhov hnyav 0.17 kg



FAQ

Q: Lub sijhawm xa khoom ntawm koj cov khoom yog dab tsi?

A: Feem ntau, lub sij hawm ua cov khoom ntawm peb lub gearboxes yog li ntawm 30-35 hnub (Rau kev txiav txim ceev, peb tuaj yeem ua kom nrawm). Lub sijhawm thauj mus los yog nyob ntawm txoj kev thauj mus los uas peb cov neeg siv khoom xaiv.



Q: Koj lub sijhawm them nyiaj yog dab tsi?

A: Peb lees txais 50% kev them nqi T / T ua ntej thiab 50% tshuav nyiaj them T / T ua ntej xa khoom. Rau cov neeg siv khoom qub, nws tuaj yeem hloov kho. Tsis tas li ntawd, Paypal tsuas yog muaj rau cov qauv.



Q: Koj puas tuaj yeem muab kev pabcuam customized?
A: Nrog peb tus kheej machining Rhiav, peb tuaj yeem ua tau raws li qhov xav tau ntawm cov neeg siv khoom sib txawv rau cov khoom lag luam customized, txawm tias qhov ntev, tuab, cov duab thiab qhov loj ntawm cov ncej tuaj yeem ua raws li cov neeg siv khoom xav tau.



Q: Koj lub Hoobkas ua li cas txog kev tswj kom zoo?

A: Qhov zoo yog qhov tseem ceeb. Peb ib txwm muab qhov tseem ceeb rau kev tswj kom zoo txij thaum pib mus txog thaum kawg ntawm kev tsim khoom. Txhua yam khoom yuav raug kuaj ua tib zoo ua ntej nws tau ntim rau cov khoom xa tuaj.
