NEMA 24 Bipolar 1.8deg 2.5Nm (347oz.in) 3A 2.1V 60x60x{11}}mm 4 Wires Stepper Tsav
Chaw tsim tshuaj paus tus lej: 60H086H-3004
Ncej Loj: 60x60mm
Lub cev muaj zog: Bipolar Stepper
Lub kaum sab xis: 1.8 deg
Tuav Torque: 2.5Nm (347oz.in)
Rated tam sim no / theem: 3A
Kev ntsuas hluav taws xob: 2.1V
Theem Resistance: 0.7ohms
Inductance: 3.1mH ± 20% (1KHz)
Lub cev Length: 86mm
- Kev xa khoom sai
- Quality Assurance
Customization Muaj
Khoom Taw qhia
Technical Parameter
|
Yam khoom |
Specifications |
|
Kauj ruam Angle Accuracy |
±5% |
|
Resistance raug |
±10% |
|
Inductance Qhov tseeb |
±20% |
|
Kub nce |
80k Max. |
|
Ambient Kub |
-20 degree ~ +50 degree |
|
Rwb thaiv tsev Resistance |
10OMΩMin.@500VDC |
|
Dielectric zog |
Ib feeb @ 500VAC∙5mA Max. |
|
Ncej Radial Ua Si |
0.06Max.@450g |
|
Ncej Axial Ua Si |
0.08Max.@100g |
Technical Specification
|
Qauv No. |
Polar |
Rated |
Tam sim no / |
Kev tiv thaiv / |
Inductance / |
tuav |
#ntawm |
Rotor |
Qhov hnyav |
Ntev |
|
|
V |
A |
Ω |
mH |
oz-in ib |
kgf · cm |
g cm;ua2 |
kg |
mm |
|||
| 60H086H-3004 | Bipolar | 2.1 | 3 | 0.7 | 3.1 | 347 | 25 | 4 | 800 | 1.4 | 86 |
Rub tawm Torque Curve
FAQ
Q: Vim li cas stepper motors tsis feem ntau yog thawj qhov kev xaiv rau kev siv ceev ceev uas yuav tsum tau muaj kev sib hloov ceev?
A: 1. Inertia thiab Rotor Mass: Stepper motors muaj ib tug kuj siab rotor inertia piv rau lwm yam motors. Qhov inertia no tuaj yeem txwv lawv lub peev xwm los ua kom nrawm thiab nrawm nrawm, ua rau lawv tsis haum rau cov ntawv thov uas xav tau kev hloov pauv ceev ceev lossis kev coj ua.
2. Torque-Speed yam ntxwv: Stepper motors pom ib tug poob nyob rau hauv muaj torque raws li qhov ceev nce. Qhov no yog hu ua torque-speed yam ntxwv nkhaus. Raws li qhov ceev ntawm lub zog stepper nce, lub torque muaj los kov yeej cov khoom txo qis, uas tuaj yeem txwv nws lub peev xwm los tswj cov zis tawm ntawm qhov nrawm dua.
3. Natural Resonance thiab Vibrations: Stepper motors muaj peev xwm ua tau tej yam ntuj tso resonance frequencies vim lawv cov khoom siv hluav taws xob thiab hluav taws xob. Ntawm los yog ze ntawm cov resonant zaus, lub cev muaj zog qhov kev ua tau zoo tuaj yeem cuam tshuam, ua rau muaj kev vibrations, txo qhov raug, thiab txawm tias muaj peev xwm hla cov kauj ruam. Kev ua haujlwm siab ceev tuaj yeem coj lub cev muaj zog los ze zog rau nws cov resonant zaus, ua rau nws muaj kev cuam tshuam rau cov teeb meem no.
4. Kev tswj qhov system txwv: Qhov ceev ntawm lub tshuab stepper tuaj yeem ua haujlwm tau los ntawm kev muaj peev xwm ntawm kev tswj hwm thiab tus tsav lub cev muaj zog. Lub kaw lus tswj yuav tsum muaj peev xwm tsim cov kauj ruam pulses ntawm lub siab zaus, thiab tus tsav lub cev muaj zog yuav tsum muaj peev xwm muab cov theem tam sim no thiab qhov hluav taws xob txaus los tsav lub cev muaj zog ntawm qhov nrawm dua. Cov kev txwv ntawm kev tswj hwm tuaj yeem ua rau muaj kev txwv ceev ntawm lub tshuab stepper.
