NEMA 23 Bipolar 0.9deg 1.15Nm (159.7oz.in) 2.8A 2.5V 57x57x55mm 4 Wires Stepper Tsav

NEMA 23 Bipolar 0.9deg 1.15Nm (159.7oz.in) 2.8A 2.5V 57x57x55mm 4 Wires Stepper Tsav

Chaw tsim tshuaj paus tus lej: 57H055HM-2804
Ncej Loj: 57x57mm
Lub cev muaj zog: Bipolar Stepper
Lub kaum sab xis: 0.9 deg
Tuav Torque: 1.15 Nm (159.7 oz.in)
Kev ntsuas hluav taws xob: 2.5V
Rated Tam sim no / theem: 2.8A
Theem Resistance: 0.9 ohms
Inductance: 4.5 mH ± 20% (1KHz)
Lub cev Length: 55mm

Xa kev nug
  • Kev xa khoom sai
  • Quality Assurance
  • Customization AvailableCustomization Muaj
Khoom Taw qhia

Technical Parameter

Yam khoom

Specifications

Kauj ruam Angle Accuracy

±5%

Resistance raug

±10%

Inductance Qhov tseeb

±20%

Kub nce

80k Max.

Ambient Kub

-20 degree ~ +50 degree

Rwb thaiv tsev Resistance

100MΩMin.@500VDC

Dielectric zog

Ib feeb @ 500VAC∙5mA Max.

Ncej Radial Ua Si

0.06Max.@450g

Ncej Axial Ua Si

0.08Max.@450g



Technical Specification

Qauv No.

Polar

Rated
Qhov hluav taws xob

Tam sim no /
Theem

Kev tiv thaiv /
Theem

Inductance /
Theem

tuav
Torque

# ntawm
Coj

Rotor
inertia

Qhov hnyav

Ntev


V

A

Ω

mH

oz-in ib

kgf · cm



g cm2

kg

mm

57H055HM-2804

 Bipolar

2.5

2.8

0.9

4.5

159.7

11.5

 4

300

0.7

55



32



Rub tawm Torque Curve

30

FAQ

Q: Koj lub Hoobkas ua li cas txog kev tswj kom zoo?

A: Qhov zoo yog qhov tseem ceeb. Peb ib txwm muab qhov tseem ceeb rau kev tswj kom zoo txij thaum pib mus txog thaum kawg ntawm kev tsim khoom. Txhua yam khoom yuav raug kuaj ua tib zoo ua ntej nws tau ntim rau cov khoom xa tuaj.



Q: Ua li cas txog qhov kev pab cuam tom qab muag?

A: Peb muab 12 lub hlis lav zoo tom qab xa tawm, peb kuj muab cov kev pab cuam tawm tswv yim thaum ntxov ntawm qhov project.



Q: Cov khoom puas tuaj yeem tsim los ntawm cov neeg siv khoom xav tau?

A: Yog lawm, cov lus qhia tshwj xeeb uas tau teev saum toj no yog tus qauv, peb tuaj yeem tsim thiab tsim khoom raws li qhov xav tau.
