42mm Geared Brushless DC Tsav
Lub 42mm geared brushless dc motors muaj ib tug ncej loj ntawm 42x42mm, muaj xws li kev lag luam planetary gearbox thiab 42mm square brushless dc motor. Lawv muaj nyob rau hauv 4 tus qauv qauv nrog lub iav piv ntawm 3: 1 txog 250: 1. Kev sib koom ua ke ntawm brushless thev naus laus zis ua kom muaj kev ua tau zoo thiab ruaj khov, thaum muaj ntau yam ntawm cov iav sib piv ua kom muaj kev siv dav dav.
- Kev xa khoom sai
- Quality Assurance
Customization Muaj
Khoom Taw qhia
Mechanical Dimension
General Specification
| Hom winding | hnub qub |
| Hall Effect Angle | 120 degree (Lub kaum ntse ntse hluav taws xob) |
| Ncej Axial Ua Si | 0.025 hli |
| Ambient Kub | 0 degree -+50 degree (tsis muaj condensation)) |
| Ambient Humidity | 85% (tsis muaj condensation) |
| Max. Radial Force | 50N |
| Max. Axial quab yuam | 20N |
| Rwb thaiv tsev Class | chav kawm B |
| Dielectric zog | one minute@500VAC.5mA |
| Rwb thaiv tsev Resistance | 100MΩ Min.@500VDC |
Kev sib txuas hluav taws xob
| Lead NO. | Xim Xim | Lead Gauge | Kev sib txuas |
| 1 | Liab | UL1007/26AWG | VCC |
| 2 | Dub | GND | |
| 3 | Daj | HALL A | |
| 4 | Dawb | HALL B | |
| 5 | Xiav | HALL C | |
| 6 | Txiv kab ntxwv | UL1007/22AWG | Phase U |
| 7 | Ntsuab | Phase V | |
| 8 | Xim av | Phase W |
Gearbox Parameter
| Theem | Ib theem | Ob theem | Peb theem | ||||||||||||||||||
| Kev txo qis | 3 | 4 | 5 | 7 | 9 | 10 | 15 | 16 | 20 | 25 | 28 | 35 | 40 | 50 | 100 | 100 | 125 | 140 | 175 | 200 | 250 |
| Ntev 1 (mm) | 41 | 48.5 | 58 | ||||||||||||||||||
| Rated load (Nm) | 3.5 | 10 | 15 | ||||||||||||||||||
| Backlash (degree) | 0.8 degree Max | 1.6 degree Max | 2.4 degree Max | ||||||||||||||||||
| Nominal input ceev (rpm) | 3000 rpm | ||||||||||||||||||||
Technical Specification
| Qauv No. | Rov qab EMF Constant | Rated Voltage | Ceev | Rated Torque | Hwj chim | Rated Tam sim no | Tsis-load Ceev | Tsis muaj load tam sim no | Resistance/kab-kab | Inductance / kab-kab | Ntev |
| V/krpm | VDC | rpm ua | N.m | W | A | rpm ua | A | Ω | mH | mm | |
| 42BL02402-0026-XXX | 4.1 | 24 | 4000 | 0.062 | 26 | 1.77 | 6700 | 0.19 | 1.76 | 3.2 | 40 |
| 42BL02402-0053-XXX | 6.1 | 24 | 4000 | 0.125 | 52.5 | 3.4 | 6500 | 0.53 | 0.78 | 1.26 | 60 |
| 42BL02402-0078-XXX | 4.3 | 24 | 4000 | 0.185 | 77.5 | 4.8 | 6000 | 0.32 | 0.76 | 1 | 80 |
| 42BL02402-0105-XXX | 4.1 | 24 | 4000 | 0.251 | 105 | 6 | 5900 | 1 | 0.52 | 0.783 | 100 |
Lus Cim: Cov neeg siv khoom tsuas yog yuav tsum tau muab qhov nrawm thiab lub zog ntawm qhov kawg ua tiav lub cev muaj zog, thiab peb yuav xaiv lub cev muaj zog thiab gearbox haum rau koj daim ntawv thov.
FAQ
Q: Puas yog geared brushless DC motors lub zog txuag?
A: Yog, geared brushless DC motors muaj npe nrov rau lawv lub zog ua haujlwm. Kev tshem tawm cov txhuam hniav hauv lawv cov qauv tsim tau txo qis zog poob. Tsis tas li ntawd, kev sib koom ua ke ntawm kev tswj hluav taws xob txhawb nqa cov motors kom zoo tswj kev ceev thiab torque, ntxiv dag zog rau lawv cov kev ua tau zoo. Qhov kev ua tau zoo no ua rau lawv xaiv zoo rau cov ntawv thov uas txo qis kev siv hluav taws xob yog qhov tseem ceeb.
Q: Kuv yuav xaiv txoj cai geared brushless DC lub cev muaj zog rau kuv qhov project li cas?
A: Txhawm rau xaiv lub cev muaj zog, muaj qee yam uas yuav tsum tau xav txog, xws li xav tau torque, ceev, qhov loj me, thiab lub voj voog ua haujlwm. Thov koj xav sab laj nrog peb pab neeg muag khoom, peb cov neeg muag khoom yuav pab koj xaiv tus qauv tsim nyog tshaj plaws.
Q: Dab tsi yog qee qhov teeb meem nrog geared brushless DC motors?
A: Cov teeb meem tuaj yeem suav nrog overheating, iav hnav, thiab teeb meem hluav taws xob. Kev tu thiab kev siv kom zoo tuaj yeem pab tiv thaiv cov teeb meem no.
Q: Koj yuav tiv thaiv cov motors li cas thaum lub sij hawm thauj mus los los tiv thaiv kev puas tsuaj?
A: Txhawm rau tiv thaiv lub cev muaj zog thaum lub sijhawm thauj mus los, peb siv cov khoom ntim ua npuas ncauj. Txhua lub cev muaj zog tau ua tib zoo muab tso rau hauv ib lub hnab ntim rau hauv cov ntim kom tsis txhob muaj kev sib tsoo thiab tiv thaiv kev vibrations uas yuav tshwm sim thaum caij tsheb npav, ua kom lawv tuaj txog nyab xeeb.
Q: Hom kev pab cuam tom qab muag koj puas muab?
A: Peb muab cov kev pab cuam tom qab muag tag. Peb cov khoom tuaj nrog 12- lub hlis lav zoo txij li hnub xa khoom. Tsis tas li ntawd, peb muab cov kev pab tswv yim tawm tswv yim thaum ntxov ntawm qhov project.
Q: Koj puas muaj qhov kev txiav txim yam tsawg kawg nkaus (MOQ)?
A: Peb qhov kev txiav txim yam tsawg kawg nkaus (MOQ) tuaj yeem sib txawv nyob ntawm cov khoom. Qee cov khoom yuav muaj MOQ tshwj xeeb, thaum lwm tus tuaj yeem muaj rau kev yuav khoom me me. Thov hu rau peb pab neeg muag khoom kom paub ntau ntxiv txog MOQ rau cov khoom tshwj xeeb uas koj xav tau.
